Advanced Hydraulic System: Equipped with high-pressure pumps and precision valves to ensure smooth operation, low noise, and stable pressure maintenance during the curing cycle.
Intelligent PLC Control: Features a user-friendly HMI (Human-Machine Interface) that allows operators to program pressure, temperature, and pressing time for consistent product quality.
Automatic Degassing Function: To prevent bubbles and cracks, the machine includes an adjustable multi-stage degassing (venting) process, essential for premium melamine finishing.
Energy-Efficient Heating: High-precision electric heating plates provide uniform heat distribution, reducing energy consumption while shortening the production cycle.
Robust Frame Design: Built with heavy-duty steel to withstand long-term high-pressure environments, ensuring a lifespan of 15+ years with minimal maintenance.
|
ZT300T SINGLE COLOR HYDRAULIC PRESS MACHINE
|
|
Technical parameter
|
Cylinder diameter
|
450 mm
|
|
|
Total pressure
|
300 tons
|
|
|
Table size
|
700 * 800 mm
|
|
|
Trip
|
560 mm
|
|
|
Guide post diameter
|
110 mm
|
|
|
Machine weight
|
5500 kgs
|
|
|
Machine size
|
2250*1360*2250 mm
|
|
|
Oil reservoir capacity
|
486 L
|
|
|
Maximum pressure
|
210KG/CM2
|
|
|
Average Powder Consumption
|
11KW/H
|
|
|
|
Machine configuration
|
Heat shield
|
|
|
|
Heating plate thickness
|
|
|
|
Heating mode
|
|
|
|
Heating capacity
|
|
|
|
Electric machinery
|
|
|
|
Oil pump
|
|
|
|
Solenoid valve
|
|
|
|
Full oil valve
|
|
|
|
PLC
|
|
|
|
POD
|
|
|
|
Price
|
|
Why Choose Our Melamine Compression Machine?
High Yield Rate: Minimize rejects with precise temperature control ($pm 1^{circ}text{C}$) and pressure stability.
Versatility: Suitable for various raw materials, including Melamine Formaldehyde (MF) and Urea-Formaldehyde (UF) molding powders.
Fast Cycle Times: Optimized hydraulic movements reduce idle time, significantly boosting your daily output.
Global Compliance: Manufactured according to CE and ISO standards to meet international safety and quality requirements.
